First Alert FA142C

– 20 –
Compatible System Sensor 4-Wire Smoke/Combustion Detectors
1412 4-wire ionization products of combustion detector.
2412 4-wire photoelectric smoke detector.
2412TH 4-wire photoelectric smoke detector w/135º F (57º C) heat
detector.
A77–716B EOL relay module (supervisory module for wired 4-wire fire
zone).
2112/24T Low-profile 4-wire photoelectric smoke detector w/135º F
(57º C) heat detector.
Programming the Hard-Wired Zones
1. With at least one 2-line Alpha keypad (FA550KP) connected to the keypad
terminals on the control, power up the system temporarily. If you had
previously connected the AC transformer to the control panel, you need
only plug in the transformer (to 120VAC outlet) to power up the system.
2. Enter the programming mode by keying the following on the Alpha keypad:
INSTALLER code (4 1 1 1) + 8 + 0.
Data fields
✱
22 RF SYSTEM, and
✱
25 WIRED EXPANSION/RELAY USED,
must be programmed as required before continuing.
3. Press
✱
56. Note that this is an interactive programming mode. You will
use it to program zone numbers, zone types, and alarm report codes for
hard-wired zones.
Note: If you enabled the 5800 wireless system in field
✱
22 (a “2” entry),
the first screen prompt will be “Program Tool?... 0 = No 1 = Yes”.
Enter “0” (No). The next prompt will ask you to enter zone number.
Enter Zn Num.
(00 = Quit) 01
Default Zone Number ↑
after after entering
✱
56
Enter the first zone number that you wish to
program (or [0][0] to exit zone programming). If
you are starting with zone 1, leave as is and
press [
✱
] to continue.
If programming another zone, enter the desired
zone number, 02, 03, etc. (zone 03 is shown in
the next display). Press [
✱
] to continue.
Typical summary display
Zn ZT – RC In L
03 03 – 00 HW: –
A summary display will appear, showing the
present status of that zone's programming.
Zn = zone number.
ZT = zone type.
RC = report code for that zone.
In = input type of zone (HW will be displayed).
Values displayed are currently programmed
values. The summary display at the left shows
the default values (except for zone number 3
shown entered, its default zone type being 03).
If programmed satisfactorily, press [#] to back
up one step and enter the next zone number.
If you want to change a zone’s programming,
press [
✱
]. A prompt for Zone Type will appear.
↓
Zone Number
03 Zone Type
Perimeter 03
Zone Type
↑
Each zone must be assigned a zone type,
which defines the way in which the system re-
sponds to faults in that zone. See “Response
Type Definitions” section in the separate
Programming Guide for an explanation of
each zone type.
Enter the desired zone type code, from the list
on the next page.
The example on the left shows zone type “03”
(Perimeter) entered (this is the default for
zone 3).
