– 38 –
Compatible 5800 Series Transmitters (Continued)
Enter As Input
Model Product Device Type Description
5819 Shock Processor RF • Connects to externally mounted
Transmitter inertia-type shock detector (not
supplied).
• Has built-in tampered cover switch.
• Has 3 unique input (loop) codes:
Loop 1:
Terminals for a wired, N.C.
sensor loop.
Loop 2:
For a closed circuit contact
loop using the built-in reed switch in
conjunction with a magnet.
Loop 3:
Terminals for a wired,
closed circuit contact loop.
5827 Wireless Keypad House ID • Can be used to turn the burglary
protection on and off.
• Features the same built-in panic
functions as wired keypads.
• The keypad is identified as zone
"00" on wired keypads when it
transmits with a low battery.
5827BD Wireless Two-Way House ID • Operates the system similarly to
Keypad wired keypads.
(used with 5800TM) • Can indicate system status via its 3
LEDs and sounder.
• Includes 3 panic keys.
• House ID must be set.
• Requires 5800TM Transmitter
Module.
5850 Glass Break Detector RF • Requires both sound and shock of
(GBD) breaking glass to cause alarm to be
transmitted.
5890 PIR Detector RF • Dual element passive infrared
detector/transmitter with selectable
pulse count.
Note
: There is a 3-minute lock-out
between fault transmissions to
conserve battery life.
5899 Magnets Package of 4 magnets for use with
5816 and 5817 transmitters.
Programming the RF Transmitters (5800 RF Systems)
1. With at least one 2-line Alpha keypad connected to the keypad terminals,
power up the system temporarily. If you had previously connected the AC
transformer to the control panel, you need only plug the transformer in (to
120VAC outlet) to power up the system.
2. Enter the programming mode by keying: Installer Code + 8 + 0.
Data field
✱
22: RF SYSTEM TYPE, must have been programmed for a 5800
RF system before continuing (“2” entered in that field).
