– 48 –
CHOICES FOR ZONE TYPES
00 = Not Used 04 = Interior Follower 08 = 24 Hr Aux
01 = Entry/Exit #1 05 = Trouble Day/Alarm Night 09 = Fire
02 = Not used 06 = 24 Hr Silent 10 = Interior w/Delay
03 = Perimeter 07 = 24 Hr Audible
CHOICES FOR SYSTEM OPERATION
20 = Arming–Stay 33 = Any Burglary Alarm 39 = Any Fire Alarm
21 = Arming–Away 34 = Code + # + 7 Key Entry 40 = Bypassing
22 = Disarming (Code + OFF) 35 = Code + # + 8 Key Entry 41 = AC Power Failure
31 = End of Exit Time 36 = At Bell Timeout** 42 = System Batt. Low
32 = Start of Entry Time 38 = Chime 58 = Duress
**Or at Disarming, whichever occurs earlier.
02 Stop: Zn List
No List 0
If a zone list will be used to STOP, or restore, the relay action, enter the zone list
(ZL) number 1, 2, or 3 (to be programmed in
✱
81 mode). If not used, enter 0.
Press the [
✱
] key to continue.
02 Stop: Zn Typ
Not Used 00
If a zone type or system operation will be used to STOP the relay action, enter
the appropriate two digit code (see the "ZT" choices listed above). If not, enter
00.
Press the [
✱
] key to continue.
02 A EV ZL ZT
STT 0 0 0 00
This screen again displays a summary of the current relay START
programming.
Press the [
✱
] key to continue.
02 A EV ZL ZT
STP – – 0 00
This screen again displays a summary of the current relay STOP programming.
Press the [
✱
] key to continue.
The display then returns again to the first screen so that the next relay number
to be programmed can be entered, or enter [0][0] to end relay programming.
Previously entered data can be reviewed by pressing [#] [8] [0]. After the relay
number is chosen, press [
✱
] to go to the next screens. This is a review mode
only, and data cannot be changed.
Example of Output
Relay Programming
A lamp is to be turned on when any one of 3 specific zones are faulted or
when any 24-hour auxiliary zone is disturbed. We want to turn off the
lamp manually without affecting the arming status of the system.
In field
✱
80 we choose Output Relay 01 and program the Action (A) to be "2"
(Close and stay closed). The Event we are looking for to
start
the relay action
is a fault, so we will program "2" in (EV). We will use Zone List 1 for the 3
specific zones, so we will program "1" in (ZL), and we will program these 3
zones in field
✱
81's Zone List 1.
The second condition for turning on the indicator is triggering a 24-hour aux.
zone (Zone Type 08), so we will program (ZT) as "08".
To
stop
relay action and turn off the indicator, we do not want to use a restore
of any zone, so we will program a "0" for the "
Restore
of"
Zone List (ZL). To
choose a manual entry of User Code + [#] + [7] to turn it off, we will program
(ZT) as "34" (see “Choices for System Operation” in the table above).
If no other relay is to be programmed we go to field *81 and program the 3
specific zones in Zone List 1.
Press
✱
81. (Zone Lists for Output Relays). This interactive menu mode is
applicable only if you have programmed
✱
80 mode.
Refer to the Programming Form worksheet for
✱
81 Mode in the separate
Programming Guide.
