Zone List Displays
[
Zone List No.
(00 = Quit) 01
Upon keying
✱
81, this screen will appear. Enter the Zone List Number 01, 02,
or 03 to program (or 00 to end these entries). Press the [
✱
] key to advance.
In the following displays, zone list 01 has been selected for programming.
01 Enter Zn Num.
(00 = Quit) 00
Enter each zone number to add to the zone list by first entering the zone
number, then pressing the [
✱
] key (example, 01
✱
, 02
✱
, 03
✱
).
After all zones desired are entered, press 00 to advance.
01 Del Zn List?
0 = No 1 = Yes 0
To delete the zone list, enter 1 (Yes). All zones in the zone list will be deleted
automatically and programming will return to the first screen.
To save the zone list, enter 0 (No) to advance.
01 Delete Zone?
0 = No 1 = Yes 0
To delete a zone or zones in a zone list enter 1 (Yes) to advance.
01 Zn to Delete?
(00 = Quit) 00
Enter each zone to be deleted from the list, followed by the [
✱
] key. After all
zones to be deleted are entered, enter 00 to return to the first screen so that
another list can be programmed, if desired.
Notes:
• Any list may include any or all of the system's zone numbers.
• A zone list can be assigned to more than one output relay.
•
If you only want to review what has been programmed previously
, enter
[#][8][1]. The review can be advanced by using the [
✱
] key.
When finished, enter [0][0]
✱
to quit. No programmed values can be changed
in this mode.
When programming in
✱
80 and
✱
81 interactive menu modes is
completed, exit the programming mode by keying
✱
99.
