– 21 –
Zone Types
00 = Zone Not Used
01 = Entry/Exit #1
02 = Not used
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24 Hr Silent
07 = 24 Hr Audible
08 = 24 Hr Aux
09 = Fire
10 = Interior w/Delay
20 = Arm Stay *
21 = Arm-Away *
22 = Disarm*
23 = No Alarm
Response
*
20, 21. & 22 used for 5800 Systems only
When the display shows the zone type you
want, press [
✱
] to continue.
You must enter “00” as the zone type for any hard-wired zones that are not
used.
03 Report Code
1st 03 2nd 12 3C
The report code consists of 2 hexadecimal
digits, each in turn consisting of 2 numerical
digits. For example, for a report code of "3C",
enter [0][3] for "3" and [1][2] for "C". Refer to the
SYSTEM COMMUNICATION
section for com-
plete information on report codes, if necessary.
Enter the desired report code and then press [
✱
]
to continue.
Typical summary display
Zn ZT – RC In L
03 03 – 3C HW: –
A summary display will appear, showing the
data for the zone that was just programmed.
If it is programmed satisfactorily, press [
✱
] to
continue.
Program Alpha?
0 = No 1 = Yes 0
The next request is to enter Alpha descriptors
for the zones. The entry may be done now
(enter 1), or may be done at a later time using
✱
82 interactive mode (enter 0). See the
ALPHA
DESCRIPTOR PROGRAMMING
section for
specific procedure.
Enter Zn Num.
(00 = Quit) 04
Enter next zone number ↑
If “0” (no) was entered above, the system will
return to the Enter Zone Number prompt.
Proceed with the programming for the next
zone, i.e., [
✱
] and zone number.
Programming Panic Keys
When programming zones, note the following:
The defaults for panic key pairs or individual panic keys are:
Zone 07. Keys [
✱
]
& [#], or Key B: zone type 06 (24-hr silent).
Zone 95. Keys [1] & [
✱
], or Key A: zone type 00 (not used).
Zone 96. Keys [3] & [#], or Key C: zone type 00 (not used).
Panic keys are programmed (or re-programmed) by keying the zone number,
e.g.,
✱
07,
✱
95, and
✱
96, and entering the desired zone type that will provide
the desired panic function for each of these keys, using the list of zone types
below.
06 = 24 Hr Silent
07 = 24 Hr Audible
08 = 24 Hr Aux
09 = Fire
