First Alert FA142C

– 87 –
FA550KP
REMOTE KEYPAD
1. Physical: 5-1/16" W x 6-3/8" H x 1-3/4" D (129mm x 162mm x 45mm).
2. Electrical: Voltage Input: 12VDC; Current Drain: 140mA.
3. Interface Wiring: Same as FA210KP.
4281L, 4281M, 4281H
RF RECEIVERS
(5700 System)
and
5881L, 5881M, 5881H
RF RECEIVERS
(5800 System)
1. Physical: 7-3/8" (188mm) W x 4-3/8" (112mm) H x 1-7/16" (37mm) D.
Note: 10-7/8" (277mm) H with antenna.
2. Electrical: Voltage Input: 12VDC; Current Drain: 35mA.
3. Interface Wiring: Same as 4127.
4. Range: 200ft (60m) nominal indoors from wireless transmitters (the
actual range to be determined with system in TEST mode).
5. Zones: (With the FA142C)
4281L: accepts up to 4 transmitters.
4281M or 4281H: accepts up to 8 transmitters.
5881L/5882L*: accepts up to 8 transmitters.
5881M: accepts up to 16 transmitters.
5881H/5882H: accepts up to 30 transmitters.
5800TM
TRANSMITTER
MODULE
used with 5827BD
Wireless 2-Way Keypad
1. Physical: 2-1/4" W x 4-1/8" H x 7/8" D (57mm x 105mm x 22mm).
2. Electrical: Voltage Input: 12VDC; Current Drain: 20mA.
3. Interface Wiring: Same as FA210KP.
4204
RELAY MODULE
1. Physical: 6-1/2" W x 4-1/4" H x 1-1/4" D (169mm x 108mm x 32mm).
2. Electrical: Voltage Input: 12VDC; Current Drain: 15mA (Relays off).
180mA (Relays on).
3. Interface Wiring: Same as FA210KP.
4. Four Output Relays: SPDT Contacts.
Rating: 2A max at 28VDC/AC.
4219
WIRED EXPANSION
MODULE
1. Physical: 6-1/2" W x 4-1/4" H x 1-1/4" D (169mm x 108mm x 32mm)
2. Electrical: Voltage Input: 12VDC; Current Drain: 35mA
3. Interface Wiring: Same as FA210KP.
4. Four Output Relays: SPDT Contacts, Rating: 2A max at 28VDC/AC
4229
WIRED EXPANSION/
RELAY MODULE
1. Physical: 6-1/2" W x 4-1/4" H x 1-1/4" D (169mm x 108mm x 32mm)
2. Electrical: Voltage Input: 12VDC; Current Drain: 35mA (Relays off)
100mA (Relays on)
3. Interface Wiring: Same as FA210KP.
4. 8 EOLR Loops (A–H): Loop A can be set for fast (10–15msec) response
to an open.
5. Two Output Relays: SPDT Contacts; Rating: 2A max at 28VDC/AC
FA4285
PHONE MODULE
1. Physical: 6-1/2" W x 4-1/4" H x 1-1/4" D (169mm x 108mm x 32mm).
2. Electrical: Voltage Input: 12VDC; Current Drain: 160mA.
3. Device Address: Permanently set to address 4.
4. Interface Wiring: See FA4285 PHONE MODULE section.
5. Telephone Line Connections: See FA4285 PHONE MODULE section.
7720PLUS/7820
LONG RANGE RADIO
1. Physical: 8-1/2" W x 9-1/2" H x 1-3/4" D (216mm x 242mm x 45mm).
2. Electrical: Voltage Input: 12VDC; Current Drain: 150mA.
3. Device Address: Set to address 3.
4. Interface Wiring: Same as FA210KP.
