FISCHBEIN F - Page 57

FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
57
MODEL MODEL F HOUSING, NEEDLE LEVER & PRESSER FOOT
Plate "A"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 40448 Assy, Housing & Cover W/ Bushings
11299 Cover, Housing


 2
6 SC83212 Screw, Soc Cap 8-32 X 1/2"
3 1 40004 Nameplate, MODEL F
4 2 11010 Stud, Feed Dog Carrier Slide
5 4 SB103214 Screw, Soc. Button 10-32 X 1/4"
6 1 11102 Cover, Looper
7 1 11108 Screw, Looper Cover
8 3 F64038 Screw, Flat Hd. #6-40 X 3/8"
9 1 11210 Plate, Throat - Standard
11212 Plate, Throat - Taping (Not Shown)
12 1 11101 Guard, Needle Bar
13 4 SC83214 Screw, Soc CAP 8-32 X 1/4 BO (SP)
14 1 11009 Plate, Cover
15 1 SB832516 Screw
16 1 11657 Cover, Slide Pad
17 1 11656 Pad, Slide
18 1 11651 Plate, Lever
19 1 SF832516 Screw, Soc Flat #8-32 X 5/16 BO
20 1 11654 Lever, Presser Foot Lifter
21 1 11655 Washer, Spring
22 1 11653 Screw, Pivot
23 1 11400 Assy., Presser Foot - Standard
11399 Assy, Presser Foot - Taping (Not Shown)
24 1 11444 Bushing, Presser Bar - Lower


 25
1 11652 Lifter, Presser Foot
26 1 11414 Spring, Presser Bar
27 1 11404 Presser Bar
28 2 11442 Bushing, Needle Bar and Presser Bar - Upper
29 1 11321 Needle
30 1 11501 Nut, Needle Bar
31 1 11443 Bushing, Needle Bar - Lower
32 1 11500 Needle Bar
33 1 11508 Wicking, OIl Lubricant


 34
1 40502 Assy, Needle Bar Clamp
35 1 11268 Nut, Lock (Nylock) 3/8 - 24 NC
36 1 A3934 Washer, Idler
37 1 11287 Pin, Pivot
38 2 WT38132 Washer, Thrust
39 1 11008 Clamp, Pivot - Needle (Mod E)
40 1 40099 Assy., Needle Bar Clamp and Lever
41 1 11510 Spring
42 2 WF10 Washer, #10 Flat
43 1 H103212 Screw, Hex Hd. 10-32 X 1/2"
44 1 11112 Assy., Complete Thread Tension
45 3 SB64014 Screw, Soc Bttn #6-40 X ¼ BO
46 1 11116 Nut, Tension - Upper
47 1 11117 Nut, Tension - Lower
48 1 11115 Spring, Thread Tension
49 2 11114 Disc, Thread Tension
50 1 11113 Stud, Thread Tension
51 3 11109 Eyelet, Thread Pulloff Eyelet
52 1 11120 Washer, Split Lock 1/4" LT Tension
53 1 11025 Lever, Needle
54 1 SB832516 Screw, Soc Bttn 8-32 X 5/16 BO (SP)
55 1 11321 Tube, Guide - Thread (Front)
56 1 SC64012 Screw, Soc CAP 6-40 X 1/2 BO
57 Ref 11104 Guard, Needle Bar (Back) – Europe
58 1 WS10 Washer, Spring #10
59 Ref SC64058 Screw, Soc Cap #6-4O X 5/8
60 Ref 11607 Bearing, Rod End


 Indicates Item has a specified torque (indica artículo conlleva torque especificado)
