FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
59
MODEL MODEL F MAIN SHAFT & LOOPER ASSEMBLY
Plate "B"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 11600 Main Shaft
1 SC54038 Screw, Soc. Cap 5-40 x 3/8”
3 1 10420 "O" - Ring
4 3 11006 Thrust Washer
5 1 11441 Bushing, Main Shaft - Rear


 6
1 11079
Assy., Connecting Rod & Eccentric (
REPLACEMENT)
7 1 40310 Assy., Looper Cam



1
*** SS83212CP ***
Screw, Soc. Set 8
-
32 X ½" (Cone Point)



1
*** SS83212 ***
Screw, Soc. Set 8
-
32 X 1/2"
8 1 WIT516 Washer, Internal Tooth 5/16"
9 1 11608 Nut, Hex (Special)
10 1 11607 Bearing, Rod End
11 1 40317 Assy., Cam Follower Arm & Stud
12 1 11308 Stud, Cam Follower
13 1 40307 Arm, Cam Follower


 14
1 SC63258 Screw, Soc. Cap 6-32 X 5/8"
15 1 40313 Washer, Flat - #6 Special
16 1 11309 Nut, Hex-Special
17 1 67693 E-Clip (1/4” shaft)
18 1 11303 Shaft, Looper
19 2 11449 Bushing, Looper Shaft – ½” Long


 20
1 11301 Holder, Looper
1 12025 Screw, Soc Set #8-32 X 3/16 HD
1 SC54038 Screw, Soc. Cap 5040 X 3/8"
21 1 11300 Looper
22 1 11447 Bushing, Main Shaft - Front
23 1 11454 Spacer
26 1 11437 Carrier Block, Feed Dog
4 SS64038FP Screw, Soc. Set 6-40 X 3/8"
1 SB832516 Screw, Soc. Btn. 8-32 X 5/16"
1 WIT8 Washer, Internal Tooth #8
1 11003 Clip, Angle
27 1 11410 Washer, Felt
28 1 11446 Slide
29 1 11203 Feed Dog
30 1 WS8 Washer, Spring #8


 31
1 SC8321 Screw, Soc. Cap 8-32 X 1"
32 1 H103238 Screw, Hex Hd. 8-32 X 3/8"
33 1 WIT10 Washer, Internal Tooth #10
34 1 11007 Bracket, Knife
35 1 11703 Knife, Stationary
36 2 F348516 Screw, Flat Hd. 3-48 X 5/16"
37 1 11702 Knife, Moving
38 2 F348316 Screw, Flat Hd. 3-48 X 3/16"
39 1 11016 Bushing, Knife Shaft
40 1 11707 Shaft, Knife
41 1 11704 Spring, Knife Tension
***
NOTE: T HE TORQUE SPECIFICATIONS MUST NOT EXCEED 13.5 in- LBS (1,52 m-N).


 Indicates Item has a specified torque (indica artículo conlleva torque especificado)
