FISCHBEIN F - Page 61

FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
61
MODEL MODEL F HANDLE AND ELECTRIC DRIVE
Plate "C"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 11450 Assy., Oil Pump
2 1 11453 Cap, Oil Reserve
3 1 SB83212 Screw, Soc. Btn. 8-32 X 1/2"
4 1 11472 Clamp, Garter Spring
5 4” (102mm) 85128 Tubing, Tugon 1/4" OD
6 1 11479 "O" Ring
7 1 SB832114 Screw, Soc. Btn. 8-32 X 1 1/4"
8 1 11475 Manifold, Outside
9 1 11478 "O" Ring
10 4.5” (114mm) 85128 Tubing, Tygon 1/4" OD
11 1 11485 Weldment, Manifold - Inside
12 1 11490 Fitting, Barbed
13 1 SF832516 Screw, Soc. Flat 8-32 X 5/16"
14 2 PS6.6X40 Spring Pin 1/4" Dia. X 1 1/2"
15 1 11018 Guard, Belt (Top)
16 1 11801 Guard, Pulley Drive
17 2 SB103214 Screw, Soc Bttn #10-32 X 1/4 BO
18 2 WN8 Washer, Nylon #8
19 1 11909 Drive Belt, Timing
20 1 11012 Hanger
21 1 11017 Clip, Hanger
22 1 WIT8 Washer, Internal Tooth #8
23 1 NH832 Nut, Hex 8-32
24 1 11904 Pulley, Machine
25 2 SB103212 Screw, Soc. Set 10-32 X 1/2"
26 1 11011 Cover, Handle
27 1 SC44034 Screw, Soc. Cap 4-40 X 3/4"
28 1 12500 Switch
30 1 11808 Cord Set
1 11777 Cord Set - 12 Volt (10 Ft.)
31 2 SC142034 Screw, Soc. Cap 1/4-20 X 3/4"
32 2 WS14 Washer, Spring 1/4"
33 1 11028 Handle (Standard Unit)
34 1 11804 Holder, Thread Guide and Cone
35 6 SF103238 Screw, Soc. Flat 10-32 X 3/8"
36 REF 11073 Strain Relief
38 1 11902 Assby,Pulley-Motor Timing
39 1 67275
Motor, 115 VAC w/ Mount
(Hinge and Screws Included)
67276
Motor, 220 VAC w/ Mount
(Hinge and Screws Included)
40 1 11815 Thread Stand (8 oz. or 16 oz. Cone)
41 1 11805 Nut, Wing-Washer Base-1/4-20
1 11190 Oil and Needles Kit (Not Shown)
1 36069 Owners Manual and Warranty Card
44 1 WN8 Washer, Nylon-#8
1 1-147 MODEL F Tool Kit
45 1 PT8OZWHITE Thread, Poly 8 Oz. Cone
