FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
63
MODEL
MODEL F HANDLE AND ELECTRIC DRIVE
(with Euro Motor-115V ONLY)
Plate "D"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1
11450 Assy., Oil Pump
2 1
11453 Cap, Oil Reserve
3 1
SB83212 Screw, Soc. Btn. 8-32 X 1/2"
4 1
11472 Clamp, Garter Spring
5 4” (102mm)
85128 Tubing, Tugon 1/4" OD
6 1
11479 "O" Ring
7 1
SB832114 Screw, Soc. Btn. 8-32 X 1 1/4"
8 1
11475 Manifold, Outside
9 1
11478 "O" Ring
10 4.5” (114mm)
85128 Tubing, Tygon 1/4" OD
11 1
11485 Weldment, Manifold - Inside
12 1
11490 Fitting, Barbed
13 1
SF832516 Screw, Soc. Flat 8-32 X 5/16"
14 2
PS6.6X40 Spring Pin 1/4" Dia. X 1 1/2"
15 1
11018 Guard, Belt (Top)
16 1
11801 Guard, Pulley Drive
17 2
SB103214 Screw, Soc Bttn #10-32 X 1/4 BO
18 2
WN8 Washer, Nylon #8
19 1
11909 Drive Belt, Timing
20 1
11012 Hanger
21 1
11017 Clip, Hanger
22 1
WIT8 Washer, Internal Tooth #8
23 1
NH832 Nut, Hex 8-32
24 1
11904 Pulley, Machine
25 2
SB103212 Screw, Soc. Set 10-32 X 1/2"
26 1
11011 Cover, Handle
27 1
SC44034 Screw, Soc. Cap 4-40 X 3/4"
28 1
12500 Switch
30 1
40066 Cord Set (2-wire)
1
11777 Cord Set - 12 Volt (10 Ft.)
31 2
SC142034 Screw, Soc. Cap 1/4-20 X 3/4"
32 2
WS14 Washer, Spring 1/4"
33 1
11028 Handle (Standard Unit)
34 1
11804 Holder, Thread Guide and Cone
35 10
SF103238 Screw, Soc. Flat 10-32 X 3/8"
36 1
11073 Strain Relief
38 1
11902 Assy,Pulley-Motor Timing
39 1
67842 Assembly, Motor, 115 VAC EURO
40 1
11815 Thread Stand (8 oz. or 16 oz. Cone)
41 1
11805 Nut, Wing-Washer Base-1/4-20
42 1
11906 Assy, Hinge-Motor Mount
43 2
11908 SCREW, SEMS-PAN HD 6-32 X 7/16
1
11190 Oil and Needles Kit (Not Shown)
1
36069 Owners Manual and Warranty Card
44 1
WN8 Washer, Nylon-#8
1
1-147 MODEL F Tool Kit
45 1
PT8OZWHITE Thread, Poly 8 Oz. Cone
