FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
68
MODEL F-A (PNEUMATIC) HANDLE AND DRIVE
PLATE "G"
ITEM
QUAN.
PART NO.
DESCRIPTION
1 1 SF832516 Screw, Soc. Flat 8-32 X 5/16"
2 2 PS6.6X40 Spring Pin - 1/4" X 1 1/2" Long
3 1 11018 Belt Guard, Top
4 1 11012 Hanger
5 1 11017 Clip, Hanger
6 1 WIT8 Washer, Internal Tooth #*
7 1 NH832 Nut, Hex 8-32
8 1 11340 Belt, Timing Drive
9 1 11339 Pulley, Main Shaft Timing
10 2 SB103212 Screw, Soc. Btn. 10-32 X 1/2"
11 1 11011 Handle Cover
12 1 SC44034 Screw, Soc. Cap 4-40 X 3/4"
13 1 11327 Valve and Maniffold Assy.
14 1 11863 Coupling
15 1 PT8OZWHITE Thread, Poly 8 oz. Cone (White)
16 2 SC142034 Screw, Soc. Cap 1/4-20 X 3/4"
17 1 11326 Handle
18 1 11804 Thread Guide and Cone Holder
19 1 11815 Thread Stand
20 1 11805 Nut, Wing-Washer Base-1/4-20
21 10 SF103238 Screw, Soc. Flat 10-32 X 3/8"
22 1.5 ft. P4969 Motor Air Supply Tubing
23 1 P4976 Nylon Clip
24 1 18107 Male Elbow 1/4" Pipe X 3/8" Tubing
25 1 11346 90 deg. Elbow 1/4" NPT Male X 1/4" NPT Fem.
26 1 11336 Air Motor Mounting Strap
27 1 11335 Air Motor
28 1 11338 Motor Timing Pulley
29 1 PS18138 Spring Pin 1/8" Dia. X 1 3/8"
30 1 11337 Air Motor Mount
31 1 11906 Motor Mount Hinge Assy.
32 1 B83212 Screw, Inding Hd. 8-32 X 1/2"
33 1 11450 Oil Pump Assy.
34 4” (102mm) 85128 Oil Pump Tubing
35 1 11472 Garter Spring
36 1 B832114 Screw, Binding Hd. 8-32 X 1 1/4"
37 1 11475 Outside Manifold
38 1 11478 "O" Ring
39 1 11479 "O" Ring
40 WN8 Washer, Nylon-#8
41 1 11490 Barbed Fitting
42 1 11485 Inside Manifold Weldment
43 1 11453 Cap, Oil Reserve
44 4.5” (114mm) 85128 Plastic Tubing
45 2 11908 Screws, Sems-Pan HD 6-32 X 7/16
46 1 11802 Guard, Pulley Drive – Modified for Air Motor
47 2 WN8 Washer, Nylon #8
48 2 SB103214 Screw, Soc Bttn #10-32 X 1/4 BO
