Fischer Panda 8000i - Opening the GFK Sound Insulation Capsule

Basics
16.1.15 Kapitel/Chapter 3: Basics - Seite/Page 33
Fig. 3.6-3: Closure openClosure open
3.6.1 Opening the GFK sound insulation capsule
Fig. 3.6-1: Lash closuresGFK sound insulation capsule with lash closures
Fig. 3.6-2: Lash closuresTo open the lash closures pull the handle in arrow
direction and lift the lash of the closure pin. After lifting
off the lashes, the sound isolation cover upper part can
be removed.
