Installation Instructions

16.1.15 Kapitel/Chapter 5: Installation Instructions - Seite/Page 99

5.18 Electronic fan control for single phase fans PXET6Q_Ziehl Abegg

The electronic fan control variety the fan rpm stepless.

5.18.1 Preset for the use with Fischer Panda generators

The Ziehl Abegg fan control is preset for the use with Fischer Panda generators. For the preset following data and

jumper settings are used.

Fig. 5.18-1: Preset
