Installation Instructions

16.1.15 Kapitel/Chapter 5: Installation Instructions - Seite/Page 89

5.11.3 Installation schematic for roof mounted radiator with expansion tank

Fig. 5.11.3-1: Roof-mounted radiator - schematic

1. Engine bleed line

2. Radiator (horizontal)

3. Coolant expansion tank (integrated)

4. T-fitting for bleed line

5. T-fitting with connection for thermal switch
