Maintenance Instructions
Page 64 Panda_6000i_System_eng_s01835.book.R01 - Chapter E: Maintenance Instructions 16.1.09
3. Press the alternator in the direction of
the thermostat casing.
4. Replace the v-belt.
Fig. E.6-3: DC alternator
5. Re-tighten V-belt
The v-belt should only be tightened to
the extent that it can be pushed to the
length of a thumb (approx. 10 mm).
6. Re-tighten the screws above and
below the alternator.
Fig. E.6-4: Drawing v-belt
