Fisher FIELDVUE DLC3010 User Manual

Instruction Manual
D102748X012
Installation
October 2014
16
Figure 2‐2. Typical Caged Sensor Mounting
A3789‐1
Figure 2‐3. Typical Cageless Sensor Mounting
A3788‐1
Digital Level Controller Orientation
Mount the digital level controller with the torque tube shaft clamp access hole (see figure 2‐4) pointing downward to
allow accumulated moisture drainage.
Figure 2‐4. Sensor Connection Compartment (Adapter Ring Removed for Clarity)
PRESS HERE TO
MOVE ACCESS
HANDLE
SLIDE ACCESS HANDLE
TOWARD FRONT OF UNIT
TO EXPOSE ACCESS HOLE
ACCESS
HOLE
MOUNTING
STUDS
SHAFT CLAMP
SET SCREW
