Instruction Manual
D102748X012
Parts
October 2014
85
Section 7 Parts7‐7‐
Parts Ordering
Whenever corresponding with your Emerson Process Management sales office about this equipment, always mention
the controller serial number. When ordering replacement parts, refer to the 11‐character part number of each
required part as found in the following parts list. Parts that do not show part numbers are not orderable.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Process Management, should
not, under any circumstances, be used in any Fisher instrument. The use of components not manufactured by Emerson
Process Management may void your warranty, might adversely affect the performance of the instrument, and could cause
personal injury and property damage.
Mounting Kits
Contact your Emerson Process Management sales
office for FS numbers for the following DLC3010
mounting options:
D Fisher
249 sensors - heat insulator for field
mounting the DLC3010
D Masoneilan 12100, 12800 Series
D Masoneilan 12100, 12800 Series with heat insulator
D Masoneilan 12200, 12300 Series
D Masoneilan 12200, 12300 Series with heat insulator
D Yamatake Honeywell
t
Type NQP
D Yamatake Honeywell Type NQP with heat insulator
D Foxboro‐Eckardt 134LD and 144LD
D Foxboro‐Eckardt 134LD and 144LD with heat
insulator
D Foxboro‐Eckardt LP167
D Foxboro‐Eckardt LP167 with heat insulator
Note
Contact your Emerson Process Management sales office for
information on the availability of additional mounting kits.
Parts Kits
Description Part Number
1* Small Hardware Spare Parts Kit 19B1643X052
Includes Qty/kit
Screw (key 7) 1
Screw, hex socket (key 13) 6
Screw, cap, hex socket (key 14) 1
Set Screw (key 20) 2
Set Screw (key 31) 2
Test Terminal (key 24) 4
Wire Retainer (key 25) 8
Nut (key 34) 4
Alarm Jumper (key 35) 2
Header Assembly (key 38) 2
2* Spare O‐Rings Kit
Includes three each of keys 21, 26, and 27 19B1643X022
3* Coupling Hardware Spare Parts Kit 19B1643X042
Includes Qty/kit
Clamp Nut (key 76) 1
Washer, Lock, Spring (key 77) 1
Bolt, lock, coupling block(key 82) 1
*Recommended spare parts
