Instruction Manual
D103176X012
Introduction and Specifications
June 2017
3
Section 1 Introduction and Specifications1‐1‐
Installation, Electrical and Pneumatic Connections, and Basic
Setup and Calibration using the Local Operator Interface
Refer to the DVC2000 Quick Start Guide (D103203X012) for DVC2000 installation,
connection, and basic setup and calibration using the local operator interface. If a copy
of this quick start guide is needed scan or click the QR code at the right, contact your
Emerson sales office, Local Business Partner, or visit our website at Fisher.com
.
Scope of Manual
This instruction manual is a supplement to the quick start guide that ships with every instrument. This instruction
manual includes specifications, detailed configuration and calibration using a Field Communicator, maintenance and
troubleshooting information and replacement part details.
Note
ValveLink software can also be used for detailed configuration and calibration, as well as performing diagnostic and performance
tests. For information on using ValveLink software with the instrument, refer to the appropriate user guide or help.
Do not install, operate, or maintain a DVC2000 digital valve controller without being fully trained and qualified in
valve, actuator, and accessory installation, operation, and maintenance. To avoid personal injury or property damage,
it is important to carefully read, understand, and follow all of the contents of this manual, including all safety cautions
and warnings. If you have any questions regarding these instructions, contact your Emerson sales office or Local
Business Partner before proceeding.
Instrument Description
The DVC2000 digital valve controller is a communicating, microprocessor-based current-to-pneumatic valve
positioner. It is designed to replace standard pneumatic and electro-pneumatic valve positioners.
In addition to the traditional function of converting an input current signal (4-20 mA) to a pneumatic output pressure,
the DVC2000 digital valve controller communicates via a local display panel and/or via the HART
®
protocol. An option
is available which provides isolated circuitry for two (2) integrated limit switches (for open/close valve indication) and a
valve position transmitter (for separate valve position feedback).
Scan or click
to access
field support
