Local Interface Flow Chart/Menu Trees
June 2017
Instruction Manual
D103176X012
60
Field Communicator Fast‐Key Sequence (Instrument Level HC, AD and PD)
Function/Variable
Fast-Key
Sequence
Coordinates
(1)
Actuator Style 1-2-5-2 4-E
Alert Record 1-2-7-6 4-G
Analog Input 2 1-E
Analog Input Calibration 1-4-1 2-E
Analog Input Range High 1-2-4-2 4-D
Analog Input Range Low 1-2-4-3 4-D
Analog Input Units 1-2-4-1 4-D
Auto Calibrate Travel 1-4-2 2-E
Auto Setup 1-1-1 2-B
Auto Tuner 1-1-1-3 3-B
Basic Setup 1-1 2-B
Burst 1-2-1-5 4-C
Calibrate 1-4 2-E
Control Mode 1-2-1-2 3-C
Custom Characteristic Table 1-2-6-5 4-F
Cycle Count 1-2-7-4-4 6-H
Cycle Count Alert 1-2-7-4 6-H
Cycle Count Alert Enable 1-2-7-4-1 6-H
Cycle Count Alert Point 1-2-7-4-2 6-H
Cycle Count Deadband 1-2-7-4-3 6-H
Damping Factor 1-1-2-3-2 4-C
Date 1-2-3-4 5-D
Descriptor 1-2-3-3 5-D
Device Description Revision 1-3-3 2-F
Device Identification 1-3-2-9 2-H
Device Information 1-3-2 2-G
Device Revision 1-3-2-2 2-G
Drive Alert Enable 1-2-7-5-1 5-H
Drive Current Fail 1-2-8-4 3-F
Drive Signal 5 1-E
Enable Integral Control 1-2-6-9-1 6-G
Expert Tuning Gains 1-1-1-4-3 5-B
Failure Alerts 7-2 1-G
Failure Group Enable 1-2-7-6-4-2 6-I
Firmware Date 1-3-2-4 2-G
Firmware Revision 1-3-2-3 2-G
Flash Rom Failure 1-2-8-1 3-E
HART Tag 1-2-3-1 5-D
HART Universal Revision 1-3-2-1 2-G
Input Characterization 1-2-6-4 4-F
Instrument Level 1-3-2-8 2-G
Instrument Mode Hot Key 1-A
Instrument Serial Number 1-2-3-6 5-D
Instrument Status 7 1-E
Integral Dead Zone 1-2-6-9-3 6-G
Integral Gain 1-2-6-9-2 6-G
Integral Settings 1-2-6-9 6-G
Limit Switch Stat Enable 1-2-7-6-4-3 6-I
LUI Language 1-2-3-8 5-D
LUI Pressure Units 1-2-4-5 4-D
Main Electronics Revision 1-3-2-5 2-G
Manual Calibrate Travel 1-4-3 2-E
Manual Setup 1-1-2 3-B
Maximum Supply Pressure 1-2-5-1 4-E
Message 1-2-3-2 5-D
Minimum Opening Time 1-2-6-8-1 6-F
Minimum Closing Time 1-2-6-8-2 6-F
NVM Fail 1-2-8-5 3-F
Operational Status 7-3 1-G
Function/Variable
Fast‐Key
Sequence
Coordinates
(1)
Polling Address 1-2-3-7 5-D
Pressure 6 1-E
Pressure Calibration 1-4-4 2-E
Pressure Sensor Failure 1-2-8-7 3-F
Pressure Units 1-2-4-4 4-D
Protection Hot Key 1-A
Reference Voltage Failure 1-2-8-3 3-F
Response Control 1-2-6 4-E
Restart 1-2-1-4 3-C
Restart Control Mode 1-2-1-3 3-C
Secondary Electronics Revision 1-3-2-6 2-G
Self Test Shutdown 1-2-8 2-D
Sensor Serial Number 1-3-2-7 2-G
Set Point Filter Time 1-2-6-6 4-F
Setup Wizard 1-1-1-1 3-B
Stroke Valve 1-5 1-D
Switch 1 Closed
(2)
1-2-9-2 3-E
Switch 1 Trip Point
(2)
1-2-9-1 3-D
Switch 2 Closed
(2)
1-2-9-4 3-E
Switch 2 Trip Point
(2)
1-2-9-3 3-E
Temperature 1-3-1-1 3-G
Temperature Comp Fail 1-2-8-2 3-F
Temperature Sensor Fail 1-2-8-6 3-F
Temperature Units 1-2-4-6 4-D
Transmitter Action
(2)
1-2-9-5 3-E
Transmitter Calibration
(2)
1-4-6 2-E
Travel 3 1-E
Travel Accumulator 1-2-7-3-4 5-H
Travel Accumulator Alert Enable 1-2-7-3-1 5-G
Travel Accumulator Alert Point 1-2-7-3-2 5-G
Travel Accumulator Dead Band 1-2-7-3-3 5-G
Travel Alert Deadband 1-2-7-1-7 5-G
Travel Alert High Point 1-2-7-1-3 5-G
Travel Alert High High Point 1-2-7-1-5 5-G
Travel Alert Low Point 1-2-7-1-4 5-G
Travel Alert Low Low Point 1-2-7-1-6 5-G
Travel Cutoff Low 1-2-6-7-4 6-F
Travel Cutoff High 1-2-6-7-3 6-F
Travel Deviation Alert Enable 1-2-7-2-1 6-G
Travel Deviation Alert Point 1-2-7-2-2 6-G
Travel Deviation Time 1-2-7-2-3 6-G
Travel High / Low Enable 1-2-7-1-1 5-F
Travel High High / Low Low Enable 1-2-7-1-2 5-F
Travel Limit High 1-2-6-7-1 6-E
Travel Limit Low 1-2-6-7-2 6-F
Travel Sensor Failure 1-2-8-8 3-F
Travel Setpoint 4 1-E
Tuning Hot Key 1-B
Tuning Set 1-1-2-3-1 4-C
Valve Group Enable 1-2-7-6-4-1 6-I
Valve Style 1-2-5-3 4-E
Valve Serial Number 1-2-3-5 5-D
Zero Control Signal 1-2-5-4 4-E
1. Coordinates are to help locate the item on the menu tree on the facing page.
2. Available only if the instrument has a transmitter and limit switches installed.
