Parts
June 2017
Instruction Manual
D103176X012
49
Section 5 Parts5‐5‐
Parts Ordering
Whenever corresponding with your Emerson sales office or Local Business Partner about this equipment, always
mention the controller serial number. When ordering parts kits, refer to the 11-character part number of each
required kit as found in the following list.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Automation Solutions should
not, under any circumstances, be used in any Fisher instrument. Use of components not supplied by Emerson Automation
Solutions may void your warranty, might adversely affect the performance of the valve, and could cause personal injury
and property damage.
The DVC2000 digital valve controller is designed with all metric fasteners and threaded connections. However,
optional inch connections are available for the two conduit entrance points (1/2 NPT) and the supply/output
pneumatic ports (1/4 NPT). Even with this option, all other fasteners and threaded connections are metric.
Parts Kits
Description Part Number
I/P Converter Kit
For GX Actuator 38B6041X182
For non-GX Rotary and Sliding-Stem 38B6041X122
Low Pressure Relay Kit (white label)
Housing A (for GX Actuator) (0 - 49 psig) GE59274X012
Housing B (for nonGX Rotary and Sliding-Stem)
(0 - 3.3 bar/0 - 49 psig) GE08910X012
High Pressure Relay Kit (green label)
Housing A (for GX Actuator) (50 - 100 psig) GE59275X012
Housing B (for nonGX Rotary and Sliding-Stem)
(3.4 - 7.0 bar/50 - 100 psig) GE08911X012
Mounting Frame Kit GE08912X012
Main Cover Assembly (see figure 5‐1, key 13) GE12427X012
EMI Shield Kit GE08913X012
Description Part Number
Feedback Array Kit
Sliding Stem (Linear)
[kit contains feedback array and hex socket cap screws, qty. 2,
washer, plain, qty. 2, external tooth lock washer, qty. 2 (only
with aluminum feedback array kit) and alignment template.
•210 mm (8-1/4 inch) kit contains feedback array and hex
socket cap screws, qty. 4, washer, plain, qty. 4, external tooth
lock washer, qty. 4 (only with aluminum feedback array kit),
alignment template and insert]. Stainless steel kits only for use
with stainless steel mounting kits.
7 mm (1/4-inch)
Aluminum GG20240X012
19 mm (3/4-inch)
Aluminum GG20240X022
Stainless steel GE65853X012
25 mm (1-inch)
Aluminum GG20240X032
Stainless steel GE65853X022
38 mm (1-1/2 inch)
Aluminum GG20240X042
Stainless steel GE65853X032
50 mm (2-inch)
Aluminum GG20240X052
Stainless steel GE65853X042
110 mm (4-1/8 inch)
Aluminum GG20240X082
Stainless steel GE65853X062
210 mm (8-1/4 inch)
Aluminum GG20243X012
Stainless steel GE65853X072
To Next Page
