Instruction Manual
D103176X012
Introduction and Specifications
June 2017
7
Table 1‐2. EMC Summary Results—Immunity
Port Phenomenon Basic Standard Test Level Performance Criteria
(1)
Enclosure
Electrostatic discharge
(ESD)
IEC 61000-4-2
6 kV contact
8 kV air
B
Radiated EM field IEC 61000-4-3
80 to 1000 MHz @ 10V/m with 1 kHz AM at 80%
1400 to 2000 MHz @ 3V/m with 1 kHz AM at 80%
2000 to 2700 MHz @ 1V/m with 1 kHz AM at 80%
A
Rated power frequency
magnetic field
IEC 61000-4-8 30 A/m at 50 Hz, 60 sec A
I/O signal/control
Burst (fast transients) IEC 61000-4-4 $1 kV A
Surge IEC 61000-4-5 $1 kV (line to ground only, each) B
Conducted RF IEC 61000-4-6 150 kHz to 80 MHz at 10 Vrms A
Performance criteria is + / - 1% effect.
1. A = No degradation during testing. B = Temporary degradation during testing, but is self-recovering.
Related Documents
Other documents containing information related to the DVC2000 digital valve controller include:
D DVC2000 Digital Valve Controller Quick Start Guide (D103203X012
)
D Bulletin 62.1:DVC2000 (D103167X012
)
D INMETRO Hazardous Area Approvals for FIELDVUE DVC2000 Digital Valve Controller (D103780X012
)
D FIELDVUE Digital Valve Controller Split Ranging (D103262X012
)
D Using FIELDVUE Instruments with the Smart HART Loop Interface and Monitor (HIM) (D103263X012
)
D Audio Monitor for HART Communications (D103265X012
)
D HART Field Device Specification - Fisher FIELDVUE DVC2000 Digital Valve Controller (D103783X012
)
D Using the HART Tri-Loopt HART-to-Analog Signal Converter with Fisher FIELDVUE Digital Valve Controllers
(D103267X012
)
These documents are available from your Emerson sales office, Local Business Partner, or at Fisher.com
.
