Instruction Manual
D103176X012
Detailed Setup and Calibration
June 2017
12
Table 2‐2. Actuator Information for Setup
Actuator
Manufacturer
Actuator Model Actuator Style Actuator Size
Starting
Tuning Set
Feedback Connection
Fisher
585C & 585CR
Piston Dbl w/ or w/o Spring. See
actuator instruction manual and
nameplate.
25, 50, 60, 68,
80, 100, 130
Undefined
SStem-Standard for travels
up to 4 inches. SStem-
Roller for longer travels
657 Spring & Diaphragm
30, 30i G
SStem-Standard
34, 34i, 40, 40i I
45, 45i, 50, 50i J
46, 46i, 60, 60i, 70,
70i & 80-100
Undefined
667 Spring & Diaphragm
30, 30i G
SStem-Standard
34, 34i, 40, 40i I
45, 45i, 50, 50i J
46, 46i, 60, 60i, 70,
70i, 76, 76i & 80-100
Undefined
1051 & 1052 Spring & Diaphragm
20, 30, 33,
40, 60, 70
Undefined Rotary
1066SR Piston Sgl w/Spring
20
27, 75
Undefined Rotary
3024 Spring & Diaphragm
GA 1.21
GA 1.31
GA 1.41
Undefined SStem-Standard
3025 Spring & Diaphragm P460, P462, P900 Undefined Rotary
GX Spring & Diaphragm
225 G
SStem-Standard
750 I
1200 K
GX 3-Way Spring & Diaphragm
225 G
SStem-Standard
750 I
Baumann
Air to Extend Spring & Diaphragm
16 C
SStem-Standard
32 D
54 Undefined
70 H
Air to Retract Spring & Diaphragm
16 C
SStem-Standard
32 D
54 Undefined
70 H
Rotary Spring & Diaphragm
10
25
54
Undefined
Undefined
G
Rotary
Setting Protection
Field Communicator Setup & Diag > Detailed Setup > Protection (1-2-2)
Some setup parameters may require changing the protection with the Field Communicator.
Two levels of protection are available:
D None—Neither setup nor calibration is protected. Allows changing calibration and setup parameters.
D Config & Calib—Both setup and calibration are protected. Prohibits changing calibration and protected setup
parameters.
