Instruction Manual
D103176X012
Detailed Setup and Calibration
June 2017
31
Press OK when you have read the message.
6. The value of the output pressure appears on the display. Press OK to display the adjustment menu.
7. From the adjustment menu, select the direction and size of adjustment to the displayed value. Selecting large,
medium, and small adjustments causes changes of approximately 3.0 psi/0.207 bar/20.7 kPa, 0.30 psi/0.0207
bar/2.07 kPa, and 0.03 psi/0.00207 bar/0.207 kPa, respectively. If the displayed value does not match the output
pressure, press OK, then repeat this step (step 7) to further adjust the displayed value. When the displayed value
matches the output pressure, select Done and go to step 8.
8. Place the instrument In Service and verify that the displayed pressure matches the measured output pressure.
Position Transmitter Calibration
Note
The position transmitter is calibrated at the factory and should not require calibration.
Note
This procedure will not move the control valve. The instrument will simulate an output for calibration purposes only.
This procedure is only available on units that have the optional position transmitter / limit switch hardware installed.
The DVC2000 digital valve controller is shipped from the factory with the position transmitter already calibrated.
To calibrate the position transmitter, select Transmitter Calibration from the Calibrate menu. Connect a current meter
in series with the +31 and -32 terminals, and a voltage source (such as the DCS analog input channel). Follow the
prompts on the Field Communicator display to manipulate the output current read by the current meter to 4 mA, and
then to 20 mA.
