Fisher FIELDVUE DVC2000 User Manual

Parts
June 2017
Instruction Manual
D103176X012
50
Description Part Number
Feedback Array Kit (cont'd)
Rotary
[Kit contains feedback assembly, pointer assembly, travel
indicator scale and M3 machine pan head screws qty. 2].
Stainless steel kits only for use with stainless steel mounting kits.
Aluminum GE71982X012
Stainless steel GE71982X022
Elastomer Kit - includes all accessible elastomers
for one complete DVC2000 unit GE08917X012
Small Hardware Kit -includes all fasteners and plugs
(except mounting hardware) for one
complete DVC2000 unit GE08918X012
High Temperature Gasket Set
Includes O-ring seal (qty 1) and insulation
gaskets (qty 2) GE26550X012
Replacement housing
Plastic Vent Construction
Housing A (for GX Actuator)
G 1/4 & M20 Metric threaded ports GE24013X012
1/4 NPT & 1/2 NPT Imperial threaded ports GE24011X012
Housing B (for nonGX Rotary and Sliding-Stem)
G 1/4 & M20 Metric threaded ports GE24012X012
1/4 NPT & 1/2 NPT Imperial threaded ports GE24010X012
Metal Vent Construction
Housing A (for GX Actuator)
G 1/4 & M20 Metric threaded ports GE74138X012
1/4 NPT & 1/2 NPT Imperial threaded ports GE74137X012
Housing B (for nonGX Rotary and Sliding-Stem)
G 1/4 & M20 Metric threaded ports GE74140X012
1/4 NPT & 1/2 NPT Imperial threaded ports GE74139X012
Metal Vent Assembly GE20435X012
Parts List (refer to figures 5‐1,
5‐2 and 5‐3)
Note
The parts contained in the Parts List are not available as individual
components. All parts are included in the Parts Kits.
I/P Converter Assembly
(1)
25 Fasteners
26 O-Ring
41 I/P Converter
231 Screen O-Ring
Relay Assembly
(2)
2 Relay
45 O-Rings
Mounting Frame Assembly
(3)
3 Mounting Frame
16 Pressure Sensor Seal
19 Fasteners
45 O-Ring
51 O-Ring
EMI Shield Assembly
(4)
11 Fasteners (3 req'd)
29 Conductive Gasket (Shield)
37 Primary Shield
1. All parts included in the I/P Converter Kit
2. All parts included in the Low Pressure or High Pressure Relay Kits
3. All parts included in the Mounting Frame Kit
4. All parts included in the EMI Shield Kit

Fisher FIELDVUE DVC2000 Specifications

General

Manufacturer	Fisher
Category	Controller
Device Type	Digital Valve Controller
Communication Protocol	HART
Input Signal	4-20 mA
Enclosure Rating	NEMA 4X, IP66
Operating Temperature	-40 to 85°C (-40 to 185°F)
Material	Aluminum
Power Supply	Loop Powered
Diagnostics	Advanced diagnostics
Output Signal	4-20 mA
Certifications	ATEX, IECEx, CSA, FM
Mounting	Integral mounting to actuator
