Instruction Manual
D103176X012
Viewing Device Variables and Diagnostics
June 2017
35
Viewing Instrument Status
Field Communicator Instrument Status (7)
Note
Instrument Status is not available for instrument level AC.
The following describes the various displays for the Instrument Status menu.
DDone—Select this when you are done viewing the instrument status.
Note
Alerts are not available with instrument level AC.
DValve Alerts—If a valve alert is active, it will appear when the Valve Alerts menu item is selected. If more than one
alert is active, they will appear on the display one at a time in the order listed below.
1. Alert Record has Entries
2. Alert Record is full
3. Instrument Time is Invalid
4. Tvl Accumulation Alert
5. Cycle Counter Alert
6. Non-critical NVM Alert
7. Power Starvation Alert
8. Drive Signal Alert
9. Tvl Lim/Cutoff Low
10. Tvl Lim/Cutoff High
11. Tvl Deviation Alrt
12. Tvl Alert Hi Hi
13. Tvl Alert Hi
14. Tvl Alert Lo Lo
15. Tvl Alert Lo
