FlaktWoods eq Controls - Power Consumption Eq

Fläkt Woods 8666 GB 2010.06
Specifications are subject to alteration without notice
Installation and maintenance instructions
Control equipment
11
When ordering the load interrupter (STAZ-80), specify the
total power consumption.
Total current is calculated in accordance with the example
below.
Supply air fan power consumption
+ Extract air fan power consumption
+ Other power consumption approx. 1 A
= Total power consumption (bbb in STAZ-80)
Exemple:
For a 3x400 V air handling unit with a 7.5 kW
supply air fan and 4 kW extract air fan. The power
consumption for each fan can be read off from the
table above.
15,5
+ 8,8
+ 1,0
= 25,3
Total 1 motor
Output
(kW)
3x230 V 3x400 V 3x230 V 3x400 V
Current
(A)
Current
(A)
Current
(A)
Current
(A)
0,55 7,6 4 3,3 1,5
0,75 10,2 5,8 4,6 2,4
1,1 14,2 7,6 6,6 3,3
1,2 – 4,6 – 1,8
1,5 16 9,2 7,5 4,1
1,7 – 6 – 2,5
2,2 24,6 11,8 11,8 5,4
3 – 14,8 – 6,9
3,1 – 10,8 – 4,9
4 34,4 18,6 16,7 8,8
5,5 49,4 25 24,2 12
7,5 62,6 32 30,8 15,5
11 – 47 – 23
15 – 63 – 31
The size of the load interrupter depends on the total
power consumption.
Power consumption eQ
