FlaktWoods eq Controls - Minimum Flows for Duct-Mounted Electric Heater; Minimum Flows for Air Handling Unit-Mounted; Electric Heater EQEK

Fläkt Woods 8666 GB 2010.06
Specifications are subject to alteration without notice
Installation and maintenance instructions
Control equipment
33
Connection
Ø/(BxH) Variant 1
Output variants, kW
Variant 2 Variant 3
Minimum flow
m
3
/s
Ø315 3 5 9 0,12
Ø400
1
5 9 15 0,19 (0,24
1
)
Ø500
2
12 17 24 0,37
800x400 12 17 24 0,48
1100x500 17 30 43 0,82
1400x600 20 34 54 1,3
1400x800 30 48 75 1,7
Air handling unit
size
aaa
Minimum flow
m
3
/s
005 0,27
008 0,50
009 0,55
011 0,7
014 0,8
018 1,1
020 1,2
023 1,6
027 1,6
032 1,9
036 2,1
041 2,4
045 2,6
047 2,8
050 3,2
054 3,2
056 3,3
063 3,7
068 3,9
072 4,2
079 4,6
090 5,3
Minimum flows for air handling unit-mounted electric air heater, EQEK
Minimum permissible air flows for duct-mounted electric air heater, EQKK
1 Rectangular air heater (400x400) with a circular connection for output variant 3 (15kW)
2 Rectangular air heater (500x500) with circular connection, all output variants
