FlaktWoods eq Controls - Overview of the Menu Structure

46Fläkt Woods 8666 GB 2010.06
Specifications are subject to alteration without notice
Installation and maintenance instructions
Control equipment
Overview of the menu structure
(The menu structure depends on which functions have
been ordered and as a result may deviate from this
Menu heading Comment
uStart page First menu when switching on the power. Displays operating
mode, mode switches and actual values for temperatures.
u Login The password is: 2000
u Main menu
u Air handling unit
u Operation status All actual values and setpoints along with control signals and status.
u Inputs Status: Analogue and digital inputs. Alarm status
u Outputs Status: Analogue and digital outputs.
u Operating mode
u Scheduler program Setting scheduler
u Night purging Settings for free cooling outside operation
u Unoccupied mode Settings for unoccup. mode heating and unoccup. mode cooling
u Boost Boost settings
u Setpoints/settings Setpoints for fan control
u Damper control Damper status and time constants
u Fan control
u Supply air fan Supply air fan status and settings
u Extract air fan Extract air fan status and settings
u Summer compensation fans Summer setpoint compensation of fans
u Winter compensation fans Winter setpoint compensation of fans
u Temperature control
u Setpoints Setpoint and dead zones for the temperature controller
u Cascade controller Controller settings for cascade control
u Mixing dampers Mixing damper status and settings
u Heat recovery Heat recovery status and settings
u Heating Heater status and settings
u Electric heater Electric heater status and settings
u Cooling Cooler status and settings
u Controllers The status and settings of the relevant controllers
u Operating period Measured operating period and reset of the runtime meter
u General functions
u Summer and winter changeover Time and temperature settings when summer starts
u Alarm management Alarm resetting and alarm outputs
u System overview Time, language, software information, save/reset settings,
communication
u System settings HMI, password management, diagnostics
u Configuration
u Configuration 1 General functions, accessories and sensors
u Configuration 2 Selection of functions and accessories
u Configuration Inputs and outputs Allocation of physical input and output signals
u Operating information Shortcut to the operating information menu
overview). All functions can be accessed by using this
overview.
