7.6 Operation menu, conguration variants
Overpressure,actual
valueatpressure
sensor(example)
Vessellllevel,actual
value(example)
Valve,
230V 1~
Valve,
230V 1~
Valve,
zero
potential
Valve,
zero
potential
Pump,
230V 1~
Pump,
230V 1~
Signal,
230V 1~
Signal,
230V 1~
Signal,
zero
potential
Signal,
zero
potential
Valve,
230V 1~
on
Valve,
230V 1~
on
+:InrangeP
A
+
-:InrangeP
A
-
Gas sensor
(option)
(Menu 8-5-2 ON)
Cycle,normal
(Menu 8-5-4 ON)
TemperaturemonitorON,
degassing OFF
(option)
MaintenancecycleON(default:ON,ifnopumpsareactivated
withinaperiodof14days)
Cycle,fast
(Menu 8-5-2 ON)
Cut-off time ON
(Menu 8-5-6 ON)
Cycle,reduced
(1. Reduction OFF
sensor signal sequence)
Testcycle(2. Reduction from
sensor signal sequence)
(8-5-3 ON)
Watertreatment,valueforquantityalreadyprocessedinlitres(top-up
withimpulsewatermeterrequired).Valueinverted:Quantityhasbeenusedup[potentialerrors,
Notes:Errorno.:55;61;31;consequentialerror:errorno.:19]
Valve,zero
potential,
on
Valve,zero
potential,
on
Pump,
230V 1~
on
Pump,
230V 1~
on
Signal,
230V 1~
on
Signal,
230V 1~
on
Signal,zero
potential,
on
Signal,zero
potential,
on
Vessellevel,
pictorial
Degassingprocess
active
(Menu 8-5-1 ON)
Min. priming water ON
[errorno.:19;10]
Min.lllevelON[error
no.:11]
Top-up,self-monitored
Degassingprocess
Drainagewithimpulsewatermeter,self-monitoring
Drainagewithoutimpulsewatermeter,self-monitoring,register
[Possiblemalfunctions:Errorno.:14;18;22-27]
[Possiblemalfunctions:Errorno.:28;29;11]
Indicationofreplenishmentinhours:minutes;withimpulsewatermeterinlitres
Indicationoffeedwithimpulsewatermeterinlitres
[Possiblefollow-onerrors:
Errorno.:19;8;10]
[Possiblefollow-onerrors:
Errorno.:11]
Replenishment,externallymonitored
Feed,externallymonitored
SPC terminalOperationindicator,eld1-6
Pump
Pump,ON(pressure
increase)
Valve
Valve,ON
(pressure
reduction)
Fig. FM.052.V01.15
