5. Product description
Thecontentsofthismanualconsistofthespecicationsforastandardexecution.Whereappropriate,thisincludesinformation
onoptionsorothercongurations.Ifoptionalextrasaresupplied,furtherdocumentationwillbesuppliedinadditiontothis
manual.
Forinstallationinstructionsandfurtherdocumentationinvariouslanguages,visitwww.amcogroup.com/manuals.
FurtherproductinformationcanbeobtainedfromtherespectiveFlamcobranchofce(seepage2).
5.1 Operating principle
70 °C
bar
2
0 3
1
bar
2
3
1
1. Cold
Theautomatcontainsasmall
amount of water. The automat
is still at rest.
5. Topping-up
Ifthewaterlevelinthevesseldrops
toacriticallevel,anappropriate
amountofwaterwillbecarefully
pumped into the system from the
water mains. This water will be
de-aerated(bypressurelossand
thePALLrings),beforeentering
thevessel.
3. Full power
Bystoringanincreasingamount
ofwaterinthetank,theautomat
keepsthesystempressurealmost
constant.Whenthesystemhas
warmedupcompletely,thevessel
willbealmostfulltocapacity.
2. Warming up
Thevolumeofwaterandthe
systempressureincreases.The
unit responds to this by opening
thesolenoidvalve.Waterowsinto
thepressurelessvessel.Thewater
inthevesselisde-aerateddueto
both the drop in pressure and the
presenceofthePALLrings.
4. Cooling down
Thevolumeofwater
and the system pressure
decreases.Thede-aerated
water is pumped from
thepressurelessvessel
backintothesystem.
This restores the system
pressure.
Flamcomat
1. Initial lling, relling and heating 3. Cooling down, minimum operation
2. Heating up, maximum operation
Flamcomatstarter
