Flexim FLUXUS G601 - Lamb Wave Transducer Specifications

B Technical Data FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 199
Lamb Wave Transducers
technical type GRG1NC3 GRH1NC3 GRK1NC3
order code GLG-NNNNL GLH-NNNNL GLK-NNNNL
transducer frequency MHz 0.2 0.3 0.5
medium pressure
1
min. extended metal pipe: 10 metal pipe: 10 metal pipe:
min. metal pipe: 15
plastic pipe: 1
metal pipe: 15
plastic pipe: 1
metal pipe:

plastic pipe: 1
inner pipe diameter d
2
min. extended 190 120 60
min. recommended 220 140 80
max. recommended 900 600 300
max. extended 1600 1000 500
pipe wall thickness
min. 11 7 4
max. 23 15 9
material
housing PPSU with stainless
steel cap 304 (1.4301)
PPSU with stainless
steel cap 304 (1.4301)
PPSU with stainless
steel cap 304 (1.4301)
contact surface PPSU PPSU PPSU
degree of protection
according to EN 60529
IP 65 IP 65 IP 65
transducer cable
type 1699 1699 1699
length 5 5 5
dimensions
length l 128.5 128.5 128.5
width b 515151
height h 67.5 67.5 67.5
operating temperature
min. °C -40 -40 -40
max. °C +170 +170 +170
temperature
compensation
xxx
1
depending on application, typical absolute value for natural gas, nitrogen, compressed air
2
Lamb wave transducers: 
typical values for natural gas, nitrogen, oxygen, pipe diameters for other gases on request
pipe diameter min. recommended/max. recommended: in reflection mode and for a flow velocityof

pipe diameter max. extended: in diagonal mode and for a flow velocity of
bar
10 (d > 120 mm)
5 (d < 120 mm)
bar
15 (d > 120 mm)
10 (d < 120 mm)
mm
mm
mm
mm
mm
mm
m
mm
mm
mm
l
h
b
l
h
b
l
h
b
15 m/s
25 m/s
