154 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 21 Outputs
21.3.2 Function Test
The function of the installed output can now be tested. Connect a multimeter to the in-
stalled output.
21.4 Configuration of a Frequency Output as a Pulse Output
A frequency output sends a signal with a frequency that depends on the volume flow
rate. The frequency output can be configured in such way that the source item can be to-
talized by using each period of the output signal as the increment.
Installation of a Frequency Output (Optional)
Select yes to activate the output. Press ENTER.
Enter a test value. The value must be indicated on the con-
nected multimeter. Press ENTER.
Select yes to repeat the test. Press ENTER.
Select Frequency F1 in Special Funct.\SYSTEM
settings\Proc. outputs. Press ENTER.
Select yes if the output has not been installed. Press EN-
TER.
or
Select no if the output has already been installed. Press
ENTER.
Select in the scroll list the measuring channel to be as-
signed to the output as the source channel. Press ENTER.
Select in the scroll list Measuring value (but not Im-
puls!). Press ENTER.
If Measuring value has been selected and the source
item can be totalized, a request will be indicated whether
the frequency output is to be configured as a pulse output.
Select yes. Press ENTER.
I1: Test output ?
no >YES<
I1: Test value =
5.00 m3/h
I1: Test output ?
no >YES<
Install Output ↕
Frequency F1
F1 Source chan.↕
Channel A:
F1 Source item ↕
Measuring value
Setup as pulse ?
no >YES<
