20 Inputs FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 143
Select the list items for T-Fluid/Outle, T(3) and T(4) of measuring channel A and
the other activated channels accordingly. Press ENTER after each input.
20.2 Selection of the Temperature Probe
If necessary, select the temperature probe for Input T2...T4 accordingly.
Select the temperature input to be assigned to measuring
channel A as the supply temperature.
Select the list item Fixed input val. if the temperature
is to be entered manually before the measurement.
Select the list item No measuring if no supply tempera-
ture is to be assigned to measuring channel A.
Press ENTER.
Note! The configuration of a measuring channel will be stored when the
next channel is selected. The configuration dialog of a channel must
be finished to store the changes.
Select Special Funct.\SYSTEM settings\Proc.
inputs. Press ENTER.
Select the list item PT100/PT1000.
Select the temperature probe.
SYSTEM settings ↕
Proc. inputs
Proc. inputs ↕
PT100 / PT1000
Input T1 ↕
>PT100< pt1000
