144 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x 20 Inputs
20.3 Assignment of Other Inputs to the Measuring Channels
Select the list items for ext.Input(2)...(4) of measuring channel A and the other acti-
vated channels accordingly.
20.4 Activation of the Inputs
The activation of the inputs in program branch Output Options will only be displayed if
the transmitter has inputs of the corresponding type and they have been assigned to a
measuring channel.
20.4.1 Activation of the Temperature Inputs
Temperature inputs must be activated if the measured temperatures are to be displayed,
stored and/or transmitted or if the measured temperature is to be used for the interpola-
tion of the viscosity and the density of the medium.
Select Special Funct.\SYSTEM settings\Proc.
inputs. Press ENTER.
Select the list item Link other inp..
Select the first input to be assigned to measuring channel
A. Only the installed inputs are displayed in the scroll list.
Select the list item No measuring if no input is to be as-
signed to measuring channel A.
Press ENTER.
Note! The configuration of a measuring channel will be stored when the
next channel is selected. The configuration dialog of a channel has
to be finished to store the changes.
Select in the program branch Output Options the chan-
nel for which a temperature input has to be activated.
The temperature inputs assigned to the channel will be
displayed one after another. Select yes for the tempera-
ture inputs that are to be activated.
Note! The total number of measured values that can be stored will be re-
duced if a temperature input is activated.
SYSTEM settings ↕
Proc. inputs
Proc. inputs ↕
Link other inp.
To Next Page
