Introduction
5
5.1.2
Quality
assurance
7
Figure
5.3
Checking
hot
glue
on
cardboard
box
es
1.
Computer
running
custom-made
software.
2.
CA
T
-6
Ethernet
cables.
3.
Industrial
Po
wer
over
Ethernet
(PoE)
switches
with
fiber-optic
posts.
4.
Fiber-optic
cable.
5.
FLIR
A400/A500/A700
Streaming
cameras.
6.
Industrial
process
to
be
monitored,
e.g.
items
on
a
conve
yor
belt.
7.
Example
of
thermal
image.
#T810409;
r.
AH/78915/78915;
en-US
10
13
15
