configurations
11
11.2
P
ower/Digital
I/O
connector
and
cable
Figure
11.3
Male
A-coded
M12
Power/Digital
I/O
connector
Pin
Configuration
1
EXTPWR_RTN
2
EXTPWR_IN
3
F
AUL
T_A
4
F
AUL
T_B
5
DIGOUT1A
6
DIGOUT1B
7
DIGOUT2A
8
DIGOUT2B
9
DIGIN1
10
DIGIN2
11
Not
Connected
12
DIGIN_RTN
Figure
11.4
Cable
M12
to
pigtail
Section
A—A
Wire
colour
1
Black
2
Red
3
Green
4
Purple
5
Y
ellow
6
Pink
7
Orange
8
Brown
9
White
10
Grey
11
Light
blue
12
Blue
#T810409;
r.
AH/78915/78915;
en-US
40
43
45
