FLIR E series User Manual

Procedure to set
up thermal fusion
Follow this procedure:
1
Push to display the menu system.
In the menu system, select . This will display a submenu.
2
In the submenu, select Thermal fusion.3
Push .
4
To change the portion of infrared in the image, do one of the following:
■
Push the joystick left/right to select , then push the joystick up/down
to change the bottom temperature level.
■
Push the joystick left/right to select , then push the joystick up/down
to change the top temperature level.
■
Push the joystick left/right to select , then push the joystick up/down
to change the top and bottom temperature level at the same time, and
left/right to change the temperature span.
5
42 Publ. No. T559597 Rev. a554 – ENGLISH (EN) – September 27, 2011
16 – Working with thermal fusion and picture-in-picture image modes
