Technical data26
Image annotations
Area measurement information No
Sensors (built in)
No
GPS
Yes: location data automatically added to every still
image and the first frame in video from built-in GPS
Video recording in camera
Radiometric infrared–video recording RTRR (.csq)
Non-radiometric infrared–video recording H.264 to memory card
Dual recording No
Visual video recording H.264 to memory card
Video streaming
Radiometric infrared–video streaming
(compressed)
Yes: over UVC or RTSP (Wi-Fi)
Non-radiometric video streaming (compressed: IR,
MSX, visual, Picture in Picture)
• H.264 (AVC) over RTSP (Wi-Fi)
• MPEG4 over RTSP (Wi-Fi)
• MJPEG over UVC and RTSP (Wi-Fi)
Dual streaming No
Visual video streaming No
Digital camera
Resolution 5 MP with LED light
Focus Fixed
Field of view
53° × 41°
Video lamp Built-in LED light
Laser pointer
Laser alignment Position is automatically displayed on the infrared
Laser distance meter Activated by a dedicated button
Laser
Class 2, 0.05–40 m (1.6–131 ft.) ±1% of measured
distance
Data communication interfaces
Interfaces USB 2.0, Bluetooth, Wi-Fi
Bluetooth
Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
Audio Microphone and speaker for voice annotation of
images
USB USB Type-C: data transfer/video/power
USB standard USB 2.0 High Speed
Video out DisplayPort
Video connector type
DisplayPort over USB Type-C
Power system
Battery type Rechargeable Li-ion battery
Battery voltage 3.6 V
#T810190; r. AI/41890/41890; en-US
133
