Handling
the
camera
10
10.15.2
Mounting
the
lanyard
strap
Follow
this
procedure:
1.
Remo
ve
the
camera
batter
y
.
2.
Starting
with
the
FLIR
logo
part,
thread
the
lanyard
strap
through
the
attachment
point
at
the
base
of
the
camera.
3.
Pull
the
entire
lany
ard
strap
through
the
attachment
point
until
it
stops.
10.16
W
rist
strap
10.16.1
General
The
wrist
strap
can
also
be
used
to
attach
a
carabiner
to
the
camera.
#T810190;
r
.
AI/41890/41890;
en-US
43
54
56
