6,46in
164,2mm
4,57in
116,08mm
10,96in
278,39mm
0,91in
23,23mm
1,92in
48,81mm
4,45in
113,07mm
0,42in
10,55mm
1,95in
49,5mm
0,87in
22mm
0,4in
10,25mm
10,71in
271,96mm
1,9in
48,3mm
0,4in
10,25mm
7,64in
193,99mm
3,27in
82,96mm
2,29in
58,18mm
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
1(1)
T130127
Basic dimension drawing Exx
FRGU
2016-12-20
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
B
1:2
Scale
