2. SYSTEM INSTALLATION
WARNING
Voltages exist in the SeaFLIR II Imaging System. The
SeaFLIR II Imaging System must be de-energized (TURNED
OFF at Circuit Breaker) before installing or removing.
2.1 System Diagram
The SeaFLIR II Imaging System is to be installed per the respective host
platform alteration or alteration instructions. Figure 2-1 depicts a typical
installation.
CAUTION
Proper grounding of the SeaFLIR II Imaging System must be
accomplished at time of installation into the host platform.
Refer to the FLIR Interface Control Document (ICD),
18400-940. Additional service and installation information
can be obtained by contacting FLIR at (978) 901-8000.
Improper installation of the system will cause display
problems and can damage the system components.
