CHAPTER 6
Engineering Drawings
The following drawings are provided with this manual. Please note that drawings are provided for reference only.
Drawings and part numbers can become obsolete as a part of Flow’s ongoing product improvement. If part numbers
are replaced by new numbers, Flow Customer Service will inform you when you order new parts. The drawings listed
below are either illustrated in this chapter, or provided on the CD-ROM.
HyperJet 94i-S
042570 HyperJet 94i-S assembly
020505 Booster pump assembly
020552 Water filter assembly
020851 Hydraulic schematic
041158 Reservoir assembly
042014 Cover package
A-22018-1 Heat exchanger
HyperJet 94i-D
042210 HyperJet 94i-D assembly
020704-1 Water filter assembly
020850 Hydraulic schematic
040588-1 Booster pump assembly
041570-1 Heat exchanger
042013 Cover package
042451 Reservoir assembly
Subassemblies used on both models
019579 Attenuator assembly
020070 Intensifier/manifold assembly
020071 Check valve assembly
020101-X PLC enclosure assembly
019309 Bleed-down assembly
020544-X CE gauge panel assembly
020670 Motor/pump assembly
041423 Remote enclosure assembly
042809 Plumbing package
Kits
040505-1 HyperJet 94i-D label kit
040521-1 HyperJet 94i-S label kit
020708 Hose kit
