040207-1 Rev. A
Hose kit for HyperJet 94i-S Pump
# Qty Part # Description
1 1 A-0410-17 Hose assembly, ¼" ID x 17"
2 1 A-00230-40 Hose assembly, 40"
3 1 A-0410-29 Hose assembly, ¼" ID x 29"
4 1 A-0410-55.5 Hose assembly, ¼" ID x 55.5"
5 1 A-0424-22.5 Hose assembly, ¼" ID x 22.5"
6 1 A-00230-30.5 Hose assembly, 30.5"
7 1 A-00930-39 Hose assembly, ¾" ID x 39"
8 1 A-00930-55.5 Hose assembly, ¾" ID X 55.5
9 40" A-0805-5 Hose, 2" ID
10 1 A-22038-25.5 Hose assembly, 25.5"
11 1 A-22065-54 Suction hose assembly, 1" ID
12 1 A-22163-32.5 Hose assembly, 32.5"
13 1 A-0434-39.5 Hose assembly, 1" ID x 39.5"
020708-1 Rev. E
Hose kit for HyperJet 94i-D Pump
# Qty Part # Description
1 1 A-00230-35.75 Hose assembly, 35.75"
2 1 A-00840-17.75 Hose assembly,
3
8
ID
3 1 A-00930-28 Hose assembly,
3
4
ID x 28
4 1 A-0410-19.5 Hose assembly,
1
4
ID
5 1 A-0410-29.75 Hose assembly,
1
4
ID
6 1 A-0410-43.5 Hose assembly,
1
4
ID
7 1 A-22164-39 Hose assembly, 39"
9 1 A-0434-19.625 Hose assembly, 1 ID
10 1 A-04340-27 Hose assembly, 1 ID x 27"
11 1 A-0434-40 Hose assembly, 1 ID x 40"
12 1 A-0434041 Hose assembly, 1 ID x 41"
13 1 A-04340-59.75 Hose assembly, 1 ID x 59.75"
15 1 A-0805-5-40.25 Hose assembly, 2 ID x 40.25"
16 1 A-22038-24.5 Hose assembly, 24.5"
17 1 A-22038-25.25 Hose assembly, 25.25"
19 1 A-22163-33.25 Hose assembly, 37"
20 1 A-22065-43.75 Suction hose assembly, 1"
22 1 A-220650-51.25 Suction hose assembly, 1"
23 1 A-0424-43 Hose assembly,
1
4
ID x 43"
24 1 A-0805-5-39.5 Hose assembly, 2 ID x 39.5"
For the intensifier
Refer to manual M-376, 94K HyperJet™ Intensifier
Kits
014884-1 Check valve inlet repair kit
014885-1 Check valve outlet repair kit
013157-1 Low-pressure seal kit
Other parts
040015-1 Seal cartridge
© Flow International Corporation M-390 | 71
CHAPTER 6
Engineering Drawings
