STRADA PAL – MAINTENANCE MANUAL
100/149
8.4.8 Replacing the attack detection board
8.4.8.1 Preliminary operations
A. Open the maintenance door
B. Turn off the terminal
C. Unplug and remove the 27 Ah battery
8.4.8.2 Replacement
A. Unplug the cables from the attack detection board.
B. Loosen the 2 screws (1) holding the support / attack detection board assembly to
the rack.
C. Remove the attack detection board (2).
Replacing the attack detection board
8.4.8.3 Installation
A. Repeat the previous steps in reverse.
8.4.8.4 End of procedure
A. Run function 80 (initialisation).
B. Perform function 215 (attack detection function).
C. Turn on the terminal
D. Close the maintenance door
