Flowserve Logix 3200MD Plus User Manual

Logix
®
3200MD+ Digital Positioners FCD LGENIM0110-0 05/16
flowserve.com 12
16.5 Stroke Output
Table 5: Stroke Output
Feedback shaft
Rotation
Min 15°, Max 90°
45° recommended for linear applications.
16.6 Remote Mount Specifications
Table 6: Remote Mount Specifications
For entity parameters, see section 17 HAZARDOUS AREA
CERTIFICATIONS.
Remote Mount Device
Use only with Logix
®
Remote
Mount Option device.
Max Cable and Tube Distance
30.5 m (100 ft)
Operating Temperature
-52 to 85°C (-61.6 to 121°F)
16.7 Positioner Performance
Characteristics
Table 7: Performance Characteristics
Better than or equal to the following values on a 25 square inch
Mark One actuator.
Resolution
 0.25%
Linearity
 0.8% full scale
Repeatability
 0.05% full scale
Hysteresis
 1.0%
Deadband
 0.1% full scale
Sensitivity
 0.25%
Stability
 0.4%
Long term drift
 0.5%
Supply Pressure Effect
 0.2%
 NOTE: Performance tested according to ISA 75.13.
16.8 Physical Specifications
Table 8: Physical Specifications
For dimensions, see section 30 POSITIONER DIMENSIONS
Housing Material
Cast, powder-painted aluminum
EN AC-AlSi12(Fe)
Soft Goods
Fluorosilicone
Weight of Base
Positioner Without
Accessories
3.9 kg (8.3 lb) aluminum
16.9 Temperature
Table 9: Temperature
Operating Temperature
Range
-52 to 85°C (-61.6 to 185°F)
Transport and Storage
Range
-52 to 85°C (-61.6 to 185°F)
 NOTE: Reduced performance possible at low
temperatures.
16.10 ValveSight
®
DTM Software
Specifications
Table 10: ValveSight
®
DTM Software Specifications
Computer
Minimum Pentium processor running
Windows 2000, XP, Server 2003, Server
2003 R2, Server 2008 (32-bit & 64-bit
Versions), Server 2008 R2 (32-bit & 64-bit
Versions), and 7 (32-bit & 64-bit Versions).
Memory: >64MB Available HARD Disk
Space : >64MB
Ports
1 minimum available with 8 maximum
possible. (Can also communicate via
serial, PCMCIA and USB connections)
HART Modem
RS-232,
PCMCIA card, or
USB
HART Filter
May be required in conjunction with some
DCS hardware.
HART MUX
MTL 4840/ELCON 2700, P&F K System
HART Multiplexer
