17 HAZARDOUS AREA CERTIFICATIONS
 DANGER: Certifications listed on the positioner are correct for that positioner. Before using the information on this page,
ensure the certifications on the positioner label match the certifications on this page.
Table 11: Logix
®
3200MD+ Series Hazardous Locations Information
North America (FM/CSA)
Explosion Proof
Class I, Div 1, Groups B,C,D
Class I, Zone 1, AEx db IIB+H2 T4/T6 Gb IP65
Class I, Zone 1, Ex db IIB+H2 T4/T6 Gb IP65
Class II, III, Div 1 Groups E,F,G
T4 Ta = -50˚C to +80˚C
T6 Ta = -50˚C to +45˚C
Intrinsically Safe
Class I,II,III, Div 1, Groups A,B,C,D,E,F,G
Class I, Zone 0, AEx ia IIC T4/T6 Ga IP65
Class I, Zone 0, Ex ia IIC T4/T6 Ga IP65
T4 Ta = -52˚C to +85˚C
T6 Ta = -52˚C to +45˚C
Non-Incendive
Class I, Div 2, Groups A,B,C,D
T4 Ta = -52˚C to +85˚C
T6 Ta = -52˚C to +45˚C
Nema Type 4X, IP65
ATEX
Flame Proof
FM16ATEX0006X
II 2 G
Ex db IIB+H2 T4/T6 Gb IP65
T4 Ta = -52˚C to +80˚C
T6 Ta = -52˚C to +45˚C
Type “t”
FM16ATEX0006X
II 2 D
Ex tb IIIC T95˚C Db IP65
Ta = -52˚C to +55˚C
IECEx
Explosion Proof
IECEx FMG 16.0007X
Ex db IIB+H
2
T4/T6 Gb IP65
T4 Ta = -52˚C to +80˚C
T6 Ta = -52˚C to +45˚C
Type “t”
IECEx FMG 16.0007X
Ex tb IIIC T95˚C Db IP65
Ta = -52˚C to +55˚C
Intrinsically Safe
FM16ATEX0021X
II 1 G
Ex ia IIC T4/T6 Ga IP65
T4 Ta = -52˚C to +80˚C
T6 Ta = -52˚C to +45˚C
II 1 D
Ex ia IIIC T95˚C Da IP65
Ta = -52˚C to +85˚C
Type “n”
FM16ATEX0027X
II 3 G
Ex nA IIC T4/T6 Gc IP65
T4 Ta = -52˚C to +80˚C
T6 Ta = -52˚C to +45˚C
Intrinsically Safe & Type “n”
IECEx FMG 16.0015X
Ex ia IIC T4/T6 Ga IP65
T4 Ta = -52˚C to +85˚C
T6 Ta = -52˚C to +45˚C
Ex nA IIC T4/T6 Gc IP65
T4 Ta = -52˚C to +85˚C
T6 Ta = -52˚C to +45˚C
