Logix
®
3200MD+ Digital Positioners FCD LGENIM0110-0 05/16
flowserve.com 56
31.2 Spare Parts Kits
NOTE: Multi-function cards may be purchased as
upgrades and installed after the initial purchase of the
positioner. In this case, the positioner label must be
modified to reflect the change.
Table 23: Spare Parts Kits
Kit 2: Driver Module Assembly, P/N 338691.999.000
Screw, Regulator to Housing
Hex Barbed Fitting w/ Captive 0-ring
Kit 3: Spool Assembly Valve Kit, P/N 199787.999.000
Screw, Spool Valve to Housing
Kit 4: Pressure Regulator, P/N 215814.999.000
Screw, Regulator to Housing
Kit 7: Soft Goods Kit, P/N 338692.999.000
O-ring, Main Housing Cover
O-ring, Pressure Sensor to Manifold
O-ring, Regulator to Housing
O-ring, Customer Interface Cover
O-ring, Customer Interface Board
O-ring, Spool Valve to Housing
Hydrophobic Filter, Spool Valve
Chamber
O-ring, Spool Valve Cover
O-ring, Pressure Sensor Manifold to
Housing
Kit 8: Pressure Sensor Board Kit, P/N 338693.999.000
Screw, Pressure Sensor Board
O-ring, Pressure Sensor to Manifold
O-ring, Pressure Sensor Manifold to
Housing
Kit 9: Main PCB Assembly Kit, P/N 338694.999.000
Screw, Main PCB Cover Short
Screw, Main PCB Cover Long
Screw Main PCB Retaining Screw
Kit 10: User Interface Board Kit, P/N 338695.999.000
Screw, Customer Interface to Housing
O-ring, Customer Interface Board
Kit 11: Multi-Function Card, P/N 338696.999.000
Kit 12: Position Feedback Potentiometer Kit, P/N 338697.999.000
Position Feedback Potentiometer
