123B/124B/125B
Users Manual
48
Test Limits
The test limits apply to the selected bus type. To change
the test limits:
1. Push to open the MENU.
2. Use
YZ to highlight BUSHEALTH.
3. Push to open the BUS HEALTH menu.
4. Use
YZ to highlight the bus type.
Select User1 or User2 to create a customized set of
limits to test nonstandard bus systems.
Default settings are RS232 for User1 and Foundation
Fieldbus H1 for User2.
5. Push to make the change.
6. From the BUSHEALTH main screen, push 1 to
open the SETUP LIMITS menu. The header shows
the bus type.
7. Use
YZWX to highlight the property for the limit.
Note
Use 2 to set all limits to the default setting.
hxv36.eps
