Energy Logger
Function Selection Buttons
31
Phase Color/Phase Labels
The phase colors are configurable to match with the
connector panel decal. Five schemes are available:
A/L1 B/L2 C/L3 N
US black red blue white
Canada red black blue white
EU brown black grey blue
UK (old) red yellow blue black
China yellow green red blue
To change the phase color/phase labels:
1. Push .
2. Push (Instrument Settings).
3. Push to highlight Phases. Push or touch
Phases target.
4. Select one of the available schemes.
5. Push to toggle the phase label between A-B-C
and L1-L2-L3.
6. Push to confirm the selection.
Date/Time Zone
The logger stores the measurement data in universal time
coordinate (UTC) to ensure continuity in time and accounts
for time changes due to daylight saving time (DST).
To display the time stamps of the measurement data
correctly, it is required to set the time zone. The Logger
adjusts automatically to DST. For example, a 1-week
measurement started on 2-Nov-2013 8:00 am ends on
9-Nov-2013 08:00 am even though the clock was set back
on 3-Nov-2013 from 02:00 to 01:00.
To set the time zone:
1. Push .
2. Push to highlight or touch Time Zone target.
3. Push .
4. Select the regions/continents.
5. Push .
6. Continue to select the country/city/time zone until the
time zone configuration is done and the Instrument
Settings menu shows.
To set the date format:
1. Push to highlight the Date Format target.
2. Push .
3. Select one of the available date formats.
To Next Page
