Fluke 1730/BASIC - i40 s-EL Current Clamp Specifications

1730
Users Manual
52
Transducer length
iFlex 1500-12 .......................................... 305 mm (12 in)
iFlex 3000-24 .......................................... 610 mm (24 in)
iFlex 6000-36 .......................................... 915 mm (36 in)
Transducer cable diameter ......................... 7.5 mm (0.3 in)
Minimum bending radius ............................. 38 mm (1.5 in)
Output cable length
iFlex 1500-12 .............................................. 2 m (6.6 ft)
iFlex 3000-24 & iFlex 6000-36 .................... 3 m (9.8 ft)
Weight
iFlex 1500-12 .......................................... 115 g
iFlex 3000-24 .......................................... 170 g
iFlex 6000-36 .......................................... 190 g
Material
Transducer cable .................................... TPR
Coupling .................................................. POM + ABS/PC
Output cable ........................................... TPR/PVC
Operating Temperature ............................. -20 °C to +70 °C
(-4 °F to 158°F)
temperature of conductor
under test shall not exceed
80°C (176°F)
Storage temperature ................................... -40 °C to +80 °C
(-40 °F to 176 °F)
Operating relative humidity, ....................... 15 % to 85 % noncondensing
IP Rating ..................................................... IEC 60529:IP50
Operating Altitude ....................................... 2000 m (6,500 ft) up to 4000
m (13,000 ft) derate to 1000 V
CAT II/600 V CAT III/300 V
CAT IV
Storage Altitude .......................................... 12 km (40,000 ft)
Warranty ..................................................... 1 year
i40s-EL Current Clamp Specifications
Measuring range ..................................... 40mA to 4A ac / 0.4 to 40A ac
Crest factor ............................................. ≤ 3
Nondestructive current ............................ 200 A (50/60Hz)
Intrinsic Error at reference condition
[1]
..... ±0.5% of reading
Accuracy 1730 + clamp........................... ±(0.7 % of reading + 0.02% of
range)
Phase shift
<40 mA................................................ unspecified
40 mA to 400 mA ................................ < ± 1.5°
400 mA to 40 A ................................... < ± 1°
Temperature Coefficient over
operating temperature range .................. 0.015 % of reading / °C
0.027 % of reading / °F
Influence of adjacent conductor .............. ≤15 mA/A (@ 50/60 Hz)
Influence of conductor position
in jaw opening ......................................... ±0.5 % of reading (@ 50/60 Hz)
Bandwidth ............................................... 10 Hz to 2.5 kHz
Working Voltage ...................................... 600 V CATIII, 300 V CATIV
[1] Reference Condition:
• Environmental: 23 °C ±5 °C, no external electrical/magnetic field, RH 65 %
• Primary conductor in center position
Size (H x W x L) ...................................... 110 mm x 50 mm x 26 mm
(4.33 in x 1.97 in x 1.02 in)
Maximum conductor size ........................ 15 mm (0.59 in)
Output cable length ................................. 2 m (6.6 ft)
Weight ..................................................... 190 g (6.70 oz)
Material ................................................... Case ABS and PC
Output cable: TPR/PVC
Temperature operating ........................... -10 °C to +55 °C
(-14 °F to 131 °F)
Temperature, non-operating ................... -20 °C to +70 °C
(-40 °F to 158 °F)
